Overview
The BLX 3660kV brushless motor provides lots of speed and torque, and is perfectly balanced for use with the ARRMA BLX100 ESC unit.
Includes
1 x BLX 3660kV Brushless Motor
Requires
Recommended for use with #AR390069
Features
A beautifully etched black aluminum motor can provides a premium look, while a 4 pole internal configuration keeps the power supply smooth and consistent – Gold bullet connectors ensure fast and easy wire removal when you need to clean your vehicle – The aluminum motor can provides increased heat dissipation via the finned body section
SPECIFICATION
| Motor Type | Brushless |
| Motor kV (# of Turns for brushed) | 3200V |
| Poles | 4 Pole |
| Motor Length | 60mm / 2.36" |
| Diameter | 30mm / 1.18" |
| Shaft Length | 18.5mm / 0.73" |
| Shaft Diameter | 5mm / 0.2" |
| Motor Mounting Hole Diameter | M3 |
| Motor Cable Length (Including Connector) | 45mm / 1.77" |
| Motor Connector Diameter | 4mm / 0.16" |
| Motor Weight | 289g / 9.18 oz |
Specs
Product Specs
Bushing Or Bearing
Connector Type
Manufacturer #
Motor Design
Motor Size
Motor Type
Number of Poles
Outer Diameter
Part Type
Product Length
Product Weight
Recommended Speed Control
RPM/Volt (Kv)
Shaft Diameter
Shaft Length
Voltage
| Weight | 5 kg |
|---|
