  • High Speed Brushless Servo
  • Water Resistant: 7 Point Seals
  • Fully Programmable w/ REEFS Software

Features

  • High Speed Brushless Servo
  • Water Resistant: 7 Point Seals
  • Fully Programmable With REEFS Software
  • REEFS Link required for Programming
  • Voltage 4.8V – 8.4V
  • Internal: Steel Gears
  • All CNC Aluminum Casing

Specs

Product Specs

Application
1/10 Cars, Trucks, Sport Aircraft
Bearing
Triple Ball Bearings
Bushing Or Bearing
Bearing
Connector Type
Universal
Deadband
2??s
Gear Type
Metal
Input Voltage
4.8V ~ 8.4V
Maximum Servo Speed
0.07 sec/60 deg @ 6.0V, 0.06 sec/60 deg @ 7.4V, 0.05 sec/60 deg @ 8.4V
Maximum Servo Torque
210oz/in @ 6V, 270oz/in @ 7.4V, 310oz/in @ 8.4V
Product Height
1.46″ (37 mm)
Product Length
1.57″ (40 mm)
Product Weight
2.85oz (81g)
Product Width
0.78″ (20 mm)
Programmable
Yes
Servo Operating Voltage
4.8 – 8.4V (HV)
Servo Size Category
Standard
Servo Type
Digital
Spline Count
25 – Tooth
Water-Resistant
Yes
Weight 5 kg
