Specs
Product Specs
Application
1/10 – 1/8 Cars, Trucks |
Bearing
Triple Ball Bearing |
Bushing Or Bearing
Bearing |
Connector Type
JST-RCY, Universal |
Deadband
2??s |
Input Voltage
12.0 V ~ 16.8V |
Maximum Servo Speed
0.13 sec/60 deg @ 12.0V, 0.11 sec/60 deg @ 14.4V, 0.10 sec/60 deg @16.0V, 0.09 sec/60 deg @ 16.8V |
Maximum Servo Torque
640oz/in @ 12.0V, 765oz/in @ 14.4V, 860oz/in @ 16.0V, 917oz/in @ 16.8V |
Product Height
1.63″ (41 mm) |
Product Length
1.57″ (40 mm) |
Product Weight
3.12oz (88g) |
Product Width
0.78″ (20 mm) |
Servo Operating Voltage
12.0V – 16.8V (HV) |
Servo Size Category
Standard |
Servo Type
Digital |
Spline Count
25 – Tooth |
Water-Resistant
Yes |
