  • High torque both on HV and non-HV applications
  • Allows BECs of adjustable BEC ESCs to be set higher to increase performance
  • Acts as a heat sink for the motor and ESC
  • Low deadband, high resolution, with impressive holding torque for unmatched performance
  • Durable high performance finish

Specs

Product Specs

Application
Airplane or Heli
Bearing
Dual Ball Bearing
Bushing Or Bearing
Bearing
Connector Type
Universal
Connector Wire Length
11.8″ (300 mm)
Deadband
2??s
Gear Type
Metal
Maximum Servo Speed
0.094 sec/60 deg @6.0V; 0.078 sec/60 deg @ 8.4V
Maximum Servo Torque
146.43 oz-in @6.0V; 190.58 oz-in @ 8.4V
Motor Type
Brushless
Overload Protection
Yes
Product Application
Air
Product Height
1.16″ (29 mm)
Product Length
1.32″ (34 mm)
Product Weight
1.4 oz (40g)
Product Width
0.59″ (15 mm)
Programmable
No
Rotation Range
120 Degrees
Servo Operating Voltage
6.0 – 8.4V (HV)
Servo Size Category
Mini
Servo Type
Digital
Spline Count
23 – Tooth
Water-Resistant
No
Wire Gauge
22 AWG
Weight 5 kg
